1m U85 Distance Sensor Short Range Laser Measurement Machine Range Finding USB
Description:
To explore the possibilities of range finding, welcome to know more of JRT Distance Sensor Short Range Laser Measurement Machine. The laser module is very small in the world, if you want to purchase one product, please contact us and inquiry more, like what is the purchase price of a single product? With usb interface, customers can measure fast and simply.
Distance Sensor Short Range Feature:
1. Good for Industrial Application Measurement System
2. Support single measurement/continous measurement
3. Data output: RXTX, USB, RS232, RS485, Bluetooth optional
Specifications of Distance Sensor Short Range:
| Brand Name | JRT |
| Product Name | Distance Sensor Short Range |
| Model Number | U85 |
| Certification | FDA/ISO9001/CE/FCC/ROHS |
| Place of Origin | China |
| Accuracy | ±1 mm (0.04 inch) |
| Measuring Unit | meter/inch/feet |
| Measuring Range (without Reflection) | 0.03-1m |
| Measuring Time | 0.125~4 seconds |
| Laser Class | Class II |
| Laser Type | 620nm-690nm, <1mW |
| Size | 41x17x7mm (±1 mm) |
| Weight | About 10g |
| Voltage | DC2.0~3.3V |
| Electrical Level | TTL/CMOS |
| Frequency | 3HZ / 8Hz |
| Operating Temperature | 0-40 ℃ (32-104 ℉ ) |
| Storage Temperature | -25~60 ℃ (-13~140 ℉) |
| Packaging | Neutro-packing |
1. Under bad measure condition, like environment with strong light or the diffuse reflectance of measuring point over-high or low, the accuracy would have bigger amount of error: ±1 mm+40PPM.
2. Under strong light or bad diffuse reflectance of target, please use a reflector.
3. 60m can be customized.
4. Voltage can be changed by power converter LDO
5. Frequency would be affected by environment.
6. Operating temperature -10 ℃~50 ℃ can be customized.
7. Analog can be customized.
